「''System.Windows.Media.Animation.ColorAnimation' アニメーション オブジェクトは、互換性のない型 'System.Windows.Media.Brush' であるため、プロパティ 'Background' をアニメーションで表示するためには使用できません。'」というエラーがでます。
エラーの通りListView.Background
(Control.Background
)はBrush
型です。
Control.Background プロパティ (System.Windows.Controls) | Microsoft Docs
変えたかったのはSolidColorBrush
のColor
でしょう。
SolidColorBrush.Color プロパティ (System.Windows.Media) | Microsoft Docs
xml
1<!-- プロパティとバインドして色を変える ここを変えてみました ####### -->
2<DataTrigger Binding="{Binding Check}" Value="True">
3 <DataTrigger.EnterActions>
4 <BeginStoryboard>
5 <Storyboard>
6 <!--<StaticResource ResourceKey="SearchAnimation" />-->
7 <ColorAnimation
8 Storyboard.TargetProperty="Background.Color"
9 From="Chocolate"
10 To="Cyan"
11 Duration="0:0:2" />
12 </Storyboard>
13 </BeginStoryboard>
14 </DataTrigger.EnterActions>
15 <DataTrigger.ExitActions>
16 <!--<PauseStoryboard BeginStoryboardName="StopSearchAnimation" />-->
17 <BeginStoryboard>
18 <Storyboard>
19 <ColorAnimation
20 Storyboard.TargetProperty="Background.Color"
21 From="Yellow"
22 To="Red"
23 Duration="0:0:2" />
24 </Storyboard>
25 </BeginStoryboard>
26 </DataTrigger.ExitActions>
27</DataTrigger>
"Background.Color"
でも動いてしまいましたが、正しくは"(Control.Background).(SolidColorBrush.Color)"
なんでしょうかね?(いまだによくわかっていない^^;
ストーリーボードに設定されたアニメーション - Windows apps | Microsoft Docs
外に出すならColorAnimation
より、Storyboard
ごとのほうが扱いやすいです。
xml
1<Window.Resources>
2 <Storyboard x:Key="SearchAnimation">
3 <ColorAnimation
4 Storyboard.TargetProperty="(Control.Background).(SolidColorBrush.Color)"
5 From="Chocolate"
6 To="Cyan"
7 Duration="0:0:2" />
8 </Storyboard>
9 <Storyboard x:Key="StopSearchAnimation">
10 <ColorAnimation
11 Storyboard.TargetProperty="(Control.Background).(SolidColorBrush.Color)"
12 From="Yellow"
13 To="Red"
14 Duration="0:0:2" />
15 </Storyboard>
16
17 <DataTemplate DataType="{x:Type vm:Custmers}">
18 <StackPanel Margin="2">
19 <TextBox
20 Width="120"
21 HorizontalAlignment="Center"
22 FontSize="15"
23 Text="{Binding [0].Dr}" />
24 <ListView ItemsSource="{Binding}">
25 <ListView.Resources>
26 <Style TargetType="GridViewColumnHeader">
27 <Setter Property="Template" Value="{x:Null}" />
28 </Style>
29 </ListView.Resources>
30 <ListView.ItemContainerStyle>
31 <Style TargetType="ListViewItem">
32 <Style.Triggers>
33 <DataTrigger Binding="{Binding Check}" Value="True">
34 <DataTrigger.EnterActions>
35 <BeginStoryboard Storyboard="{StaticResource SearchAnimation}" />
36 </DataTrigger.EnterActions>
37 <DataTrigger.ExitActions>
38 <BeginStoryboard Storyboard="{StaticResource StopSearchAnimation}" />
39 </DataTrigger.ExitActions>
40 </DataTrigger>
41 </Style.Triggers>
42 </Style>
43 </ListView.ItemContainerStyle>
全コード再掲
xml
1<Window
2 x:Class="Q78aqeaolcdtqmb.MainWindow"
3 xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
4 xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
5 xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
6 xmlns:local="clr-namespace:Q78aqeaolcdtqmb"
7 xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
8 Width="1000"
9 Height="450"
10 mc:Ignorable="d">
11 <Window.Resources>
12 <Storyboard x:Key="SearchAnimation">
13 <ColorAnimation
14 Storyboard.TargetProperty="(Control.Background).(SolidColorBrush.Color)"
15 From="Chocolate"
16 To="Cyan"
17 Duration="0:0:2" />
18 </Storyboard>
19 <Storyboard x:Key="StopSearchAnimation">
20 <ColorAnimation
21 Storyboard.TargetProperty="(Control.Background).(SolidColorBrush.Color)"
22 From="Yellow"
23 To="Red"
24 Duration="0:0:2" />
25 </Storyboard>
26 <DataTemplate DataType="{x:Type local:Custmers}">
27 <StackPanel Margin="2">
28 <TextBox
29 Width="120"
30 HorizontalAlignment="Center"
31 FontSize="15"
32 Text="{Binding [0].Dr}" />
33 <ListView ItemsSource="{Binding}">
34 <ListView.Resources>
35 <Style TargetType="GridViewColumnHeader">
36 <Setter Property="Template" Value="{x:Null}" />
37 </Style>
38 </ListView.Resources>
39 <ListView.ItemContainerStyle>
40 <Style TargetType="ListViewItem">
41 <Style.Triggers>
42 <DataTrigger Binding="{Binding Check}" Value="True">
43 <DataTrigger.EnterActions>
44 <BeginStoryboard Storyboard="{StaticResource SearchAnimation}" />
45 </DataTrigger.EnterActions>
46 <DataTrigger.ExitActions>
47 <BeginStoryboard Storyboard="{StaticResource StopSearchAnimation}" />
48 </DataTrigger.ExitActions>
49 </DataTrigger>
50 </Style.Triggers>
51 </Style>
52 </ListView.ItemContainerStyle>
53 <ListView.View>
54 <GridView>
55 <GridViewColumn DisplayMemberBinding="{Binding No}" />
56 <GridViewColumn DisplayMemberBinding="{Binding KanjaMei}" />
57 <GridViewColumn>
58 <GridViewColumn.CellTemplate>
59 <DataTemplate>
60 <CheckBox IsChecked="{Binding ScCheck}" />
61 </DataTemplate>
62 </GridViewColumn.CellTemplate>
63 </GridViewColumn>
64 </GridView>
65 </ListView.View>
66 </ListView>
67 </StackPanel>
68 </DataTemplate>
69 </Window.Resources>
70
71 <DockPanel>
72 <Button
73 Click="AddButton_Click"
74 Content="add"
75 DockPanel.Dock="Top" />
76 <Button
77 Click="HighlightButton_Click"
78 Content="highlight"
79 DockPanel.Dock="Top" />
80 <Grid>
81 <Grid.ColumnDefinitions>
82 <ColumnDefinition />
83 <ColumnDefinition />
84 </Grid.ColumnDefinitions>
85 <!-- 元データ -->
86 <DataGrid
87 x:Name="dataGrid"
88 AutoGenerateColumns="True"
89 ItemsSource="{Binding Model.Custmers}" />
90
91 <ScrollViewer
92 Grid.Column="1"
93 Margin="5"
94 HorizontalScrollBarVisibility="Auto">
95 <ItemsControl ItemsSource="{Binding CustmersList}">
96 <ItemsControl.ItemsPanel>
97 <ItemsPanelTemplate>
98 <StackPanel Orientation="Horizontal" />
99 </ItemsPanelTemplate>
100 </ItemsControl.ItemsPanel>
101 </ItemsControl>
102 </ScrollViewer>
103 </Grid>
104 </DockPanel>
105</Window>
cs
1using System;
2using System.Collections.Generic;
3using System.Collections.ObjectModel;
4using System.Linq;
5using System.Windows;
6using CommunityToolkit.Mvvm.ComponentModel;
7
8namespace Q78aqeaolcdtqmb;
9
10
11public class Model
12{
13 public Custmers Custmers { get; } = new();
14}
15
16public class Custmer : ObservableObject
17{
18 public int No { get; }
19 public string Hyohon { get; }
20 public string KanjaMei { get; }
21 public string Dr { get; set; }
22 public bool ScCheck { get; set; }
23
24 public bool Check { get => check; set => SetProperty(ref check, value); }
25 private bool check;
26
27 public Custmer(int no, string hyohon, string kanjaMei, string dr, bool scCheck)
28 {
29 (No, Hyohon, KanjaMei, Dr, ScCheck) = (no, hyohon, kanjaMei, dr, scCheck);
30 }
31
32
33 // ダミー作成用
34 private static int no = 1300;
35 private static Random r = new();
36 private static string k = "アイウエオカキクケコサシスセソタチツテトナニヌネノナヒフヘホマミムメモヤユヨラリルレロワ";
37 public Custmer()
38 {
39 No = ++no;
40 Hyohon = $"F222{No}";
41 KanjaMei = string.Join("", Enumerable.Range(0, r.Next(5, 10)).Select(x => k[r.Next(k.Length)]));
42 Dr = $"dr{No}";
43 ScCheck = false;
44 }
45}
46
47public class Custmers : List<Custmer> { } // xamlでジェネリック指定できないので型を作る
48
49
50public partial class MainWindow : Window
51{
52 public Model Model { get; } = new();
53
54 public ObservableCollection<Custmers> CustmersList { get; } = new();
55
56 public MainWindow()
57 {
58 InitializeComponent();
59
60 foreach (var _ in Enumerable.Range(1, 100))
61 {
62 Model.Custmers.Add(new Custmer());
63 }
64 var custmers = new Custmers();
65 custmers.AddRange(Model.Custmers.Take(5));
66 CustmersList.Add(custmers);
67
68 DataContext = this;
69 }
70
71 private void AddButton_Click(object sender, RoutedEventArgs e)
72 {
73 var custmers = new Custmers();
74 // DataGridで選択中を抽出
75 custmers.AddRange(dataGrid.SelectedItems.Cast<Custmer>());
76 // ItemsControlに追加
77 CustmersList.Add(custmers);
78 }
79
80 private void HighlightButton_Click(object sender, RoutedEventArgs e)
81 {
82 // ハイライトを全クリア
83 foreach (var custmer in Model.Custmers)
84 {
85 custmer.Check = false;
86 }
87
88 // DataGridで選択中をハイライト
89 foreach (Custmer custmer in dataGrid.SelectedItems)
90 {
91 custmer.Check = true;
92 }
93 }
94}
