###現状
インターフェースにNATを設定しようとするとエラーになります。
R2(config)#int fa1/15 R2(config-if)#ip nat inside ^ % Invalid input detected at '^' marker. R2(config)#int fa1/1 R2(config-if)#ip nat outside ^ % Invalid input detected at '^' marker.
###ステータス
R2#show run Building configuration... Current configuration : 2071 bytes ! version 12.4 service timestamps debug datetime msec service timestamps log datetime msec no service password-encryption ! hostname R2 ! boot-start-marker boot-end-marker ! ! no aaa new-model memory-size iomem 5 no ip routing no ip icmp rate-limit unreachable no ip cef ! ! ! ! no ip domain lookup ip auth-proxy max-nodata-conns 3 ip admission max-nodata-conns 3 ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ip tcp synwait-time 5 ! ! ! ! ! interface FastEthernet0/0 no ip address no ip route-cache shutdown duplex auto speed auto ! interface Serial0/0 no ip address no ip route-cache shutdown clock rate 2000000 ! interface FastEthernet0/1 no ip address no ip route-cache shutdown duplex auto speed auto ! interface Serial0/1 no ip address no ip route-cache shutdown clock rate 2000000 ! interface Serial0/2 no ip address no ip route-cache shutdown clock rate 2000000 ! interface FastEthernet1/0 ! interface FastEthernet1/1 ! interface FastEthernet1/2 ! interface FastEthernet1/3 ! interface FastEthernet1/4 ! interface FastEthernet1/5 ! interface FastEthernet1/6 ! interface FastEthernet1/7 ! interface FastEthernet1/8 ! interface FastEthernet1/9 ! interface FastEthernet1/10 ! interface FastEthernet1/11 ! interface FastEthernet1/12 ! interface FastEthernet1/13 ! interface FastEthernet1/14 ! interface FastEthernet1/15 switchport trunk allowed vlan 1,2,10,20,1002-1005 switchport mode trunk ! interface Vlan1 no ip address no ip route-cache ! interface Vlan10 ip address 192.168.1.254 255.255.255.0 no ip route-cache ! interface Vlan20 ip address 192.168.2.254 255.255.255.0 no ip route-cache ! ip forward-protocol nd ! ! no ip http server no ip http secure-server ip nat pool TEST 100.100.1.1 100.100.2.2 netmask 255.255.0.0 ip nat inside source list 1 pool TEST ! access-list 1 permit 192.168.0.0 0.0.255.255 no cdp log mismatch duplex ! ! ! control-plane ! ! ! ! ! ! ! ! ! ! line con 0 exec-timeout 0 0 privilege level 15 logging synchronous line aux 0 exec-timeout 0 0 privilege level 15 logging synchronous line vty 0 4 login ! ! end
何か設定間違ってますでしょうか。
ご指摘いただけると助かります。
よろしくお願いいたします(>_<)
