あんまりよく分かってないですが、一応それっぽくなりました。
borderWidth と shadow を指定しています。
shadow を指定する場合と、指定しない場合を試してほしいと思います。
(たぶん好みの問題なので)
lang
1<!DOCTYPE html>
2<html lang="ja">
3 <head>
4 <meta charset="utf-8">
5 <link rel="stylesheet" type="text/css" href="https://cdnjs.cloudflare.com/ajax/libs/jqPlot/1.0.8/jquery.jqplot.min.css" />
6 </head>
7 <body>
8 <div id="chartdiv" style="height:400px;width:300px;"></div>
9 <script src="https://ajax.googleapis.com/ajax/libs/jquery/1.11.3/jquery.min.js"></script>
10 <script src="https://cdnjs.cloudflare.com/ajax/libs/jqPlot/1.0.8/jquery.jqplot.min.js"></script>
11 <script>
12<!--
13 $(function() {
14 $.jqplot('chartdiv', [[[1, 2],[3,5.12],[5,13.1],[7,33.6],[9,85.9],[11,219.9]]], {
15 axes: {
16 yaxis: { min:-10, max:240 }
17 },
18 series: [
19 { color:'#5FAB78' }
20 ],
21 grid: {
22 borderWidth: 0, // 1.0 だと太く見える...
23 shadow: false // これはお好みで
24 }
25 });
26 });
27//-->
28 </script>
29 </body>
30</html>
参考: jqPlot
